Through-hole mounted radial inductor with 220µH inductance and 20% tolerance. Features a 1.4A DC current rating, 380mΩ DC resistance, and a maximum operating temperature of 130°C. Designed for power applications with a radial lead pitch of 10.16mm.
PackageRadial
Current Rating1.5A
MountingThrough Hole
Inductance220uH
Quick Jump:
Technical Specifications
Pulse PE-52626 technical specifications.
General
Package/Case
Radial
Current Rating
1.5A
DC Current
1.4A
DC Resistance (DCR)
380mR
Depth
18.03mm
Height
11.68mm
Inductance
220uH
Lead Pitch
10.16mm
Lead/Base Style
Radial
Length
18.03mm
Max DC Current
1.4A
Max Operating Temperature
130°C
Military Standard
Not
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
25
Packaging
Rail/Tube
Radiation Hardening
No
RoHS Compliant
No
Shielding
Unshielded
Termination
Radial
Test Frequency
20kHz
Tolerance
20%
Width
0.71inch
Compliance
RoHS
Not CompliantNo
Datasheet
Pulse PE-52626 Datasheet
Download the complete datasheet for Pulse PE-52626 to view detailed technical specifications.
