| Package/Case | Radial |
| Current Rating | 3A |
| DC Current | 3A |
| DC Resistance (DCR) | 50mR |
| Depth | 11.43mm |
| Flammability Rating | UL94 V-0 |
| Inductance | 47uH |
| Inductance Tolerance | 20% |
| Lead Pitch | 7.62mm |
| Length | 16.51mm |
| Max Operating Temperature | 130°C |
| Military Standard | Not |
| Min Operating Temperature | -40°C |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RMS Current (Irms) | 3A |
| Series Resistance | 50mR |
| Tolerance | 20% |
| RoHS | Compliant |
