8-bit microprocessor (MPU) with a 16-bit data bus, operating at up to 60MHz. Features 40 I/Os and 12 timers/counters, with serial and SPI interfaces. Packaged in an LQFP form factor for surface mounting, this component operates from 1.8V to 3.3V and has an operating temperature range of -55°C to 85°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Rabbit Semiconductor 20-668-0024 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | LQFP |
| Data Bus Width | 16b |
| Frequency | 60MHz |
| Height | 1.5mm |
| Interface | Serial, SPI |
| Lead Free | Lead Free |
| Length | 16mm |
| Max Frequency | 60MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 3.3V |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of I/Os | 40 |
| Number of Timers/Counters | 12 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Rabbit 4000 |
| Termination | SMD/SMT |
| Width | 16mm |
| RoHS | Compliant |
Download the complete datasheet for Rabbit Semiconductor 20-668-0024 to view detailed technical specifications.
