AC/DC LED Driver, 700mA output current, 43V maximum output voltage, and 30W maximum output power. Features include over-voltage, over-current, over-temperature, and short-circuit protection. Operates from 90V to 264V AC input, with an efficiency of 85%. Offers 3kV isolation voltage and chassis mount termination. Approvals include CE, cULus, and SEMKO.
Voltage Rating264V
MountingChassis Mount, Screw
Quick Jump:
Technical Specifications
Recom RACD30-700 technical specifications.
General
Approvals
CE, cULus, SEMKO
Current - Output 1
700mA
Efficiency
85%
Features
OVP, OCP, OTP, SCP
Height
22mm
Isolation Voltage
3kV
Lead Free
Lead Free
Length
160mm
Max Input Voltage
264V
Min Input Voltage
90V
Max Operating Temperature
50°C
Min Operating Temperature
-20°C
Max Output Current
700mA
Max Output Power
30W
Max Output Voltage
43V
Max Power Dissipation
30W
Max Supply Voltage
264V
Min Supply Voltage
90V
Mount
Chassis Mount, Screw
Number of Outputs
1
Number of Segments
12
Output Current
700mA
Output Voltage
43V
Package Quantity
1
Packaging
Bulk
Ratings
IP20
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
LIGHTLINE RACD30
Termination
Terminal Block
Voltage - Output 1
43V
Voltage Rating
264V
Weight
200g
Width
50mm
Compliance
RoHS
Compliant
Datasheet
Recom RACD30-700 Datasheet
Download the complete datasheet for Recom RACD30-700 to view detailed technical specifications.
