Programmable time delay relay featuring a 5A contact current rating and 120V AC coil voltage. Offers 0.01% accuracy with a maximum operating frequency of 10Hz. Chassis mountable with screw termination, it operates within a 0°C to 65°C temperature range. Rated IP66 for water resistance and dust tightness, this RoHS compliant relay supports programmable and external reset functions.
Frequency10Hz
MountingChassis Mount
Quick Jump:
Technical Specifications
Red Lion LD2T06P0 technical specifications.
General
| Accuracy | 0.01% |
| Contact Current Rating | 5A |
| Depth | 101.6mm |
| Height | 102mm |
| Lead Free | Lead Free |
| Length | 406.4mm |
| Max Frequency | 10Hz |
| Max Operating Temperature | 65°C |
| Min Operating Temperature | 0°C |
| Max Supply Voltage (AC) | 250V |
| Min Supply Voltage (AC) | 85V |
| Max Supply Voltage (DC) | 16V |
| Min Supply Voltage (DC) | 11V |
| Mount | Chassis Mount |
| Number Of Characters Per Row | 6 |
| Operating Supply Voltage | 250V |
| Output Type | RELAY |
| Ratings | IP66, Water Resistant, Dust Tight |
| Reach SVHC Compliant | No |
| Reset | Programmable, Front Panel , External |
| RoHS Compliant | Yes |
| Series | LD |
| Termination | Screw |
| Width | 406.4mm |
Compliance
| RoHS | Compliant |
Datasheet
Red Lion LD2T06P0 Datasheet
Download the complete datasheet for Red Lion LD2T06P0 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
