The CR2477NFH-LF is a 3V lithium battery with a capacity of 950mAh. It has a diameter of 24.5mm and a height of 7.7mm. The battery is non-rechargeable and has a lead length of 3.9mm. It is available in bulk packaging with 200 units per package. The battery is lead-free and compliant with Reach SVHC regulations.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Renata CR2477NFH-LF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Renata CR2477NFH-LF technical specifications.
| Battery Size | 2477 |
| Capacity | 950mAh |
| Chemistry/Technology | Lithium |
| Diameter | 24.5mm |
| Height | 7.7mm |
| Lead Free | Lead Free |
| Lead Length | 3.9mm |
| Orientation | Horizontal |
| Output Voltage | 3V |
| Outside Diameter | 24.5mm |
| Package Quantity | 200 |
| Packaging | Bulk |
| Reach SVHC Compliant | Yes |
| Rechargeability | Non-Rechargeable |
| RoHS Compliant | No |
| Series | CR |
| Termination | Through Hole |
| Voltage Rating | 3V |
| Weight | 0.296301oz |
| Width | 24.7mm |
| RoHS | Not Compliant |
