PackageSOP
Current700uA
MountingSurface Mount
Quick Jump:
Technical Specifications
Rohm BD6210F-E2 technical specifications.
General
Package/Case
SOP
Height
1.5mm
Interface
On/Off
Lead Free
Lead Free
Length
5mm
Max Collector Current
500mA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
3V
Motor Type
Brushed
Mount
Surface Mount
Number of Outputs
1
Output Current
500mA
Package Quantity
2500
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Supply Current
700uA
Termination
SMD/SMT
Width
4.4mm
Compliance
RoHS
Compliant
Datasheet
Rohm BD6210F-E2 Datasheet
Download the complete datasheet for Rohm BD6210F-E2 to view detailed technical specifications.
