The BR93L76RFV-WE2 is an 8Kb EEPROM with a maximum operating frequency of 2MHz and a maximum supply voltage of 5.5V. It features a MICROWIRE, Serial, 3-WIRE interface and is packaged in a lead-free SSOP-8 package. The device operates over a temperature range of -40°C to 85°C and is RoHS compliant. It has a supply current of 4.5mA and supports write protection.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Rohm BR93L76RFV-WE2 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Rohm BR93L76RFV-WE2 technical specifications.
| Access Time-Max | 200ns |
| Package/Case | LSSOP |
| Density | 8Kb |
| Frequency | 2MHz |
| Interface | MICROWIRE, Serial, 3-WIRE |
| Lead Free | Lead Free |
| Max Frequency | 500kHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 8Kb |
| Memory Type | EEPROM, |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Operating Supply Voltage | 5V |
| Organization | 512X16 |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Supply Current | 4.5mA |
| Write Protection | YES |
| RoHS | Compliant |
Download the complete datasheet for Rohm BR93L76RFV-WE2 to view detailed technical specifications.
