The MCR100JZHJ101 is a 200V surface mount fixed resistor from Rohm with a resistance of 100R and a tolerance of 5%. It has a maximum operating temperature of 125°C and a minimum operating temperature of -55°C. This resistor is compliant with AEC-Q200 and is lead free. It is packaged in a 2512 case code and is available in cut tape packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Rohm MCR100JZHJ101 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Case Code (Imperial) | 2512 |
| Case Code (Metric) | 6432 |
| Package/Case | 2512 |
| Features | Automotive AEC-Q200 |
| Lead Free | Lead Free |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 1W |
| Mount | Surface Mount |
| Number of Terminations | 2 |
| Packaging | Cut Tape |
| Resistance | 100R |
| RoHS Compliant | Yes |
| Series | MCR |
| Size Code | 2512 |
| Tolerance | 5% |
| Voltage Rating | 200V |
| DC Rated Voltage | 200V |
| RoHS | Compliant |
