The FN2030-10-07 is a chassis mount power inductor from Schaffner with a current rating of 10A and a voltage rating of 250V AC. It operates within a frequency range of 0 to 400Hz and has a maximum operating temperature of 100°C. The inductor has a leakage current of 730uA and is RoHS compliant. It is packaged in a tray with 16 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Schaffner FN2030-10-07 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, ENEC |
| Current Rating | 10A |
| Depth | 54mm |
| Frequency | 400Hz |
| Height | 30.3mm |
| Inductance | 8mH |
| Leakage Current | 730uA |
| Length | 85mm |
| Max Current Rating | 10A |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -25°C |
| Mount | Chassis Mount |
| Number of Phases | 1 |
| Operating Frequency | 0 ? 400Hz |
| Package Quantity | 16 |
| Packaging | Tray |
| RoHS Compliant | Yes |
| Series | FN2030 |
| Termination | Pin |
| Voltage Rating (AC) | 250V |
| RoHS | Compliant |
