General purpose EMI/RFI line filter, chassis mountable, with a 1A current rating and 250V AC/DC voltage rating. Features 3mH inductance and operates from 0 to 400Hz, with a maximum operating temperature of 85°C. Approvals include UL, CSA, and ENEC, with solder termination and RoHS compliance. Dimensions are 64mm length, 35mm width, and 55.8mm depth.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Schaffner FN610-1-06 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, ENEC |
| Current | 1A |
| Current Rating | 1A |
| Depth | 55.8mm |
| Frequency | 400Hz |
| Height | 19.3mm |
| Inductance | 3mH |
| Leakage Current | 190uA |
| Length | 64mm |
| Max Current Rating | 1A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 250V |
| Mount | Chassis Mount, DIN Rail, Flanges, Chassis |
| Operating Frequency | 0 to 400 Hz |
| Package Quantity | 20 |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | FN 610 |
| Termination | Solder |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 250V |
| Width | 35mm |
| RoHS | Compliant |
