The LC1 Series relay from Schneider features a 24V AC coil voltage and a contact current rating of 9A. It has a compact design with dimensions of 84mm depth, 77mm length, 45mm width, and a throw configuration of 3P. The relay is suitable for operating temperatures between -5°C and 60°C and is compliant with RoHS regulations.
MountingDIN Rail
Quick Jump:
Technical Specifications
Schneider LC1D09B7 technical specifications.
General
| Coil Voltage (AC) | 24V |
| Contact Current Rating | 9A |
| Depth | 84mm |
| Length | 77mm |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -5°C |
| Mount | DIN Rail |
| Number of Poles | 3 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | LC1 |
| Termination | Screw |
| Throw Configuration | 3P |
| Width | 45mm |
Compliance
| RoHS | Compliant |
Datasheet
Schneider LC1D09B7 Datasheet
Download the complete datasheet for Schneider LC1D09B7 to view detailed technical specifications.
