Technical Specifications
Schurter 1241.6624.1131000 technical specifications.
General
| Contact Current Rating | 10A |
| Contact Material | Silver |
| Current Rating | 10A |
| Illumination Color | Red |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Solder |
| Number of Positions | 2 |
| Operating Force | 4.7N |
| Ratings | IP67 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | Blade Terminal |
| Throw Configuration | SPST |
Compliance
| RoHS | Compliant |
Datasheet
Schurter 1241.6624.1131000 Datasheet
Download the complete datasheet for Schurter 1241.6624.1131000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
