Illuminated pushbutton switch featuring a flush, round red button with SPDT (Single Pole Double Throw) contact configuration. Rated for 5A at 250VAC and 125VDC, with silver contacts and silver plating. Offers a 250V max supply voltage and 5V min supply voltage, powered by an LED illumination system. Panel mountable with snap-in installation, suitable for up to 6mm panel thickness, and equipped with 2.8mm quick connect terminals. Achieves IP40 and IP67 ratings, with a mechanical life of 1,500,000 cycles and electrical life of 200,000 cycles.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Schurter 1241.6663.1121000 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Schurter 1241.6663.1121000 technical specifications.
| Actuator Type | Round, Button, Flush |
| Package/Case | Metal |
| Color | Red |
| Contact Current Rating | 5A |
| Contact Material | Silver |
| Contact Plating | Silver |
| Contact Voltage Rating (AC) | 250V |
| Contact Voltage Rating (DC) | 125V |
| Current Rating | 5A |
| Electrical Life | 200000Cycles |
| Illumination Color | Red |
| Illumination Type | LED |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage | 250V |
| Mechanical Life | 1500000Cycles |
| Min Supply Voltage | 5V |
| Mount | Panel, Front, Snap in |
| Operating Force | 4.5N |
| Outside Diameter | 30mm |
| Package Quantity | 10 |
| Packaging | Tray |
| Panel Thickness | 6mm |
| Ratings | IP40, IP67 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | MSM |
| Switch Function | On-Mom |
| Tab Width | 2.8mm |
| Termination | Solder |
| Throw Configuration | SPDT |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 125V |
| Weight | 2.324554oz |
| Width | 30mm |
| RoHS | Compliant |
