Dual common mode choke with 40,000µH inductance per line, designed for power and signal lines. Features a 400mA maximum DC current rating and 1.2Ω DC resistance. This through-hole component has radial leads, a voltage rating of 440V AC, and operates within a temperature range of -25°C to 100°C. The self-resonant frequency is 110kHz, with a 50% inductance tolerance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Schurter DFKF-18-0001 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Radial |
| Current | 400mA |
| DC Resistance (DCR) | 1.2R |
| Depth | 17.8mm |
| Height | 0.488inch |
| Inductance | 40mH |
| Lead/Base Style | Pin |
| Length | 0.717inch |
| Max Current Rating | 400mA |
| Max DC Current | 400mA |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Number of Lines | 2 |
| Package Quantity | 48 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Self Resonant Frequency | 110kHz |
| Series | DFKF |
| Termination | Radial |
| Tolerance | 50% |
| Voltage Rating (AC) | 440V |
| Weight | 0.211644oz |
| Width | 0.701inch |
| RoHS | Compliant |
