MountingSurface Mount
Inductance3.5mH
Quick Jump:
Technical Specifications
Schurter ISNA-0249-D104 technical specifications.
General
Height - Seated (Max)
13.5mm
Inductance
3.5mH
Length
17.8mm
Max Operating Temperature
100°C
Min Operating Temperature
-25°C
Mount
Surface Mount
Package Quantity
45
Packaging
Tape and Reel
RoHS Compliant
Yes
Series
IS
Turns Ratio
1:1
Weight
0.21oz
Width
18.2mm
Compliance
RoHS
Compliant
Datasheet
Schurter ISNA-0249-D104 Datasheet
Download the complete datasheet for Schurter ISNA-0249-D104 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
