SILICON LABS

C8051F133-GQ

Datasheet

8-Bit 8051 MCU, 100MHz, 64KB FLASH, TQFP-64, I2C, SPI, UART

Silicon Labs

C8051F133-GQ

Name: C8051F133-GQ Silicon Labs
Brand: Silicon Labs
SKU: C8051F133-GQ

8-Bit 8051 MCU, 100MHz, 64KB FLASH, TQFP-64, I2C, SPI, UART

8-Bit Microcontroller (MCU) featuring an 8051 core architecture operating at up to 100MHz. This CMOS device offers 64KB of FLASH memory and 8.25KB of RAM, with a data bus width of 8 bits. Integrated peripherals include 8 ADC channels, 6 PWM channels, 5 timers/counters, and multiple communication interfaces such as I2C, SPI, UART, and USART. Designed for surface mount applications, it is housed in a TQFP package with tin contact plating and operates within a supply voltage range of 3V to 3.6V.

Frequency100MHz

PackageTQFP

MountingSurface Mount

Quick Jump:

Technical Specifications

Silicon Labs C8051F133-GQ technical specifications.

General

Access Time	100us
Package/Case	TQFP
Contact Plating	Tin
Core Architecture	8051
Data Bus Width	8b
Density	64KB
Frequency	100MHz
Height	1.05mm
Interface	I2C, SPI, UART, USART, EBI/EMI, SMBus, 2-Wire
Lead Free	Lead Free
Length	10mm
Max Frequency	100MHz
Max Operating Temperature	85°C
Max Supply Voltage	3.6V
Memory Size	64KB
Memory Type	FLASH,
Min Operating Temperature	-40°C
Min Supply Voltage	3V
Mount	Surface Mount
Number of ADC Channels	8
Number of Channels	6
Number of I/Os	32
Number of I2C Channels	1
Number of Programmable I/O	32
Number of PWM Channels	6
Number of SPI Channels	1
Number of Timers/Counters	5
Number of UART Channels	2
Operating Supply Voltage	3.3V
Oscillator Type	Internal
Package Quantity	160
Packaging	Tray
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT, Temp Sensor
Radiation Hardening	No
RAM Size	8.25KB
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Series	C8051F13x
Termination	SMD/SMT
Watchdog Timer	Yes
Width	10mm
