The SI2434-D-FS is a SPI UART bridge with a data rate of 33.6 kbps and an operating frequency of 4.92 MHz. It is available in a SOIC-48 package and is suitable for operating in temperatures ranging from 0°C to 70°C. The device is powered by a supply voltage of 3.3V and draws an operating supply current of 17mA. The SI2434-D-FS is compliant with RoHS regulations and is part of the ISOmodem series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Silicon Labs SI2434-D-FS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Silicon Labs SI2434-D-FS technical specifications.
| Package/Case | SOIC |
| Data Rate | 33600bps |
| Frequency | 4.92MHz |
| Interface | SPI, Parallel, UART |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 3V |
| Operating Supply Current | 17mA |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 48 |
| RoHS Compliant | Yes |
| Series | ISOmodem® |
| Weight | 0.006679oz |
| RoHS | Compliant |
Download the complete datasheet for Silicon Labs SI2434-D-FS to view detailed technical specifications.
