The SI52131-A11AGM is a 25MHz clock generator with a QFN package and surface mount capabilities. It operates within a supply voltage range of 3.135V to 3.465V and has a maximum operating temperature of 85°C. The device is RoHS compliant and features a PLL for clock synthesis. It consumes an operating supply current of 45mA and is available in a tray packaging format with 490 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Silicon Labs SI52131-A11AGM datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | QFN |
| Frequency | 25MHz |
| Input | Clock |
| Max Duty Cycle | 53% |
| Max Frequency | 200MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.465V |
| Min Supply Voltage | 3.135V |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Outputs | 3 |
| Operating Supply Current | 45mA |
| Package Quantity | 490 |
| Packaging | Tray |
| PLL | Yes |
| RoHS Compliant | Yes |
| RoHS | Compliant |
Download the complete datasheet for Silicon Labs SI52131-A11AGM to view detailed technical specifications.
