SI53306-B-GM

Datasheet

725MHz Clock Buffer Driver, 4-Out, LVCMOS Diff In, QFN

Silicon Labs

SI53306-B-GM

Name: SI53306-B-GM Silicon Labs
Brand: Silicon Labs
SKU: SI53306-B-GM

Active

725MHz Clock Buffer Driver, 4-Out, LVCMOS Diff In, QFN

High-performance, low-skew clock driver featuring 8 true CMOS outputs and a maximum frequency of 725MHz. This surface-mount integrated circuit operates with LVCMOS differential input and supports a supply voltage range of 1.71V to 3.63V. With a propagation delay of 0.825ns and a duty cycle of 60%, it is ideal for clock distribution applications. The compact 3x3mm QFN package ensures efficient board space utilization.

Frequency725MHz

PackageQFN

Current55mA

MountingSurface Mount

Quick Jump:

Pricing & Availability

Checking distributor stock and pricing after the page loads.

Chat with Datasheet

Technical Specifications

Silicon Labs SI53306-B-GM technical specifications.

General

Package/Case	QFN
Duty Cycle	60%
Frequency	725MHz
Height	0.85mm
Input	LVCMOS
Input Type	DIFFERENTIAL
Length	3mm
Logic Function	Clock, Translator
Max Frequency	725MHz
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Max Supply Voltage	3.63V
Min Supply Voltage	1.71V
Mount	Surface Mount
Number of Circuits	1
Number of Outputs	4
Package Quantity	100
Packaging	Tray
Propagation Delay	0.825ns
Quiescent Current	100mA
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Supply Current	55mA
Width	3mm
