The SI8231BB-D-IS is a dual driver IC with high-level output current of 500mA and low-level output current of 250mA. It operates over a temperature range of -40°C to 125°C and is compliant with RoHS and AEC-Q100 standards. The device is packaged in a SOIC package and is available in a rail/Tube packaging option. The propagation delay is 60ns, and the pulse width distortion is 5.6ns. The device is approved by CSA, VDE, UR, and CQC.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Silicon Labs SI8231BB-D-IS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | CSA, VDE, UR, CQC |
| Package/Case | SOIC |
| High Level Output Current | 500mA |
| Low Level Output Current | 250mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 500mA |
| Max Power Dissipation | 1.2W |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Outputs | 2 |
| Packaging | Rail/Tube |
| Propagation Delay | 60ns |
| Pulse Width Distortion (PWD) | 5.6ns |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q100 |
| RoHS | Compliant |
Download the complete datasheet for Silicon Labs SI8231BB-D-IS to view detailed technical specifications.
