Dual channel, 2.5kV isolation digital isolator designed for high-speed data transmission up to 150Mbps. Features unidirectional channels, 13ns propagation delay, and 4.5ns pulse width distortion. Operates with a supply voltage range of 2.7V to 5.5V and a maximum power dissipation of 150mW. This SOIC package component offers a wide operating temperature range from -40°C to 125°C and is RoHS compliant.
PackageSOIC
Quick Jump:
Technical Specifications
Silicon Labs Si8621BB-B-ISR technical specifications.
General
| Package/Case | SOIC |
| Channel Type | Unidirectional |
| Data Rate | 150Mbps |
| Isolated Power | No |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 150mW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Number of Channels | 2 |
| Operating Supply Current | 5.8mA |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Propagation Delay | 13ns |
| Pulse Width Distortion (PWD) | 4.5ns |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q100 |
| Type | General Purpose |
Compliance
| RoHS | Compliant |
