Surface mount PIN diode switch for RF applications, featuring a 50V reverse voltage and operating from -65°C to 150°C. This single PIN diode offers a maximum power dissipation of 250mW and is housed in an SC package, supplied on tape and reel. Designed for switching functions, it is RoHS compliant.
PackageSC
MountingSurface Mount
Power250mW
Quick Jump:
Technical Specifications
Skyworks Solutions SMP1345-079LF technical specifications.
General
| Package/Case | SC |
| Diode Type | PIN - Single |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -65°C |
| Max Power Dissipation | 250mW |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| Power Dissipation | 250mW |
| Radiation Hardening | No |
| Reverse Voltage | 50V |
| Reverse Voltage (DC) | 50V |
| RoHS Compliant | Yes |
| Type | Switch |
Compliance
| RoHS | Compliant |
Datasheet
Skyworks Solutions SMP1345-079LF Datasheet
Download the complete datasheet for Skyworks Solutions SMP1345-079LF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
