General purpose variable transformer with a 9.5A output current rating and a maximum output voltage of 280V. Designed for 50Hz operation, this panel or chassis mount unit offers a 9.5A secondary current. Dimensions include a height of 152.4mm, width of 158.4mm, and length of 219.9mm, with a 127mm size designation.
Frequency50Hz
Storage127mm
Current Rating9.5A
MountingPanel, Chassis
Quick Jump:
Technical Specifications
Staco 1520CT technical specifications.
General
| Current Rating | 9.5A |
| Frequency | 50Hz |
| Height | 152.4mm |
| Length | 219.9mm |
| Mount | Panel, Chassis |
| Output Current | 9.5A |
| Output Voltage | 280V |
| Reach SVHC Compliant | Unknown |
| Secondary Current | 9.5A |
| Series | 1500 |
| Size | 127mm |
| Weight | 23lb |
| Width | 158.4mm |
Compliance
| RoHS | Compliant |
Datasheet
Staco 1520CT Datasheet
Download the complete datasheet for Staco 1520CT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
