Power Relay, 4-pole, 3 Normally Open (NO) and 1 Normally Closed (NC) contacts, featuring a 24 VDC coil with 800mW power consumption and 720 Ohm resistance. Contact ratings include 8A switching current at 250VAC and 400VAC maximum, with Tin/Silver contact material. This through-hole mount relay operates within a -25°C to 70°C temperature range and offers IP67 environmental protection.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 4-1415053-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 4-1415053-1 technical specifications.
| Coil Current | 33.333A |
| Coil Power | 800mW |
| Coil Resistance | 720R |
| Coil Type | Non-Latching |
| Coil Voltage (AC) | 24V |
| Coil Voltage (DC) | 24V |
| Contact Current Rating | 8A |
| Contact Material | Tin, Silver |
| Contact Type | 3 makers, 1 breaker |
| Contact Voltage Rating (AC) | 250V |
| Depth | 13mm |
| ELV | Compliant |
| Height | 16.5mm |
| Lead Free | Lead Free |
| Length | 1.575inch |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (AC) | 400V |
| Mount | Through Hole, PCB |
| Number of Contacts | 4 |
| Number of Poles | 4 |
| Package Quantity | 10 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Relay Type | Safety RELAY |
| RoHS Compliant | Yes |
| Series | SR4, SCHRACK |
| Switching Current | 8A |
| Termination | PCB |
| Throw Configuration | 4PST, SPST, 3PST |
| Voltage Rating (AC) | 400V |
| DC Rated Voltage | 24V |
| Weight | 30g |
| Width | 0.512inch |
| RoHS | Compliant |
Download the complete datasheet for TE Connectivity 4-1415053-1 to view detailed technical specifications.
