4-1571999-5

4-Pos SPST Rotary DIP Switch, 1A, 24VDC, Surface Mount

4-position, SPST rotary and slide actuator DIP switch featuring a 2.54mm terminal pitch and surface mount termination with gull wing style. This switch offers a 1A contact current rating with gold-plated copper alloy contacts and a 24V DC maximum voltage rating. Designed for a 0.1-inch pitch, it operates within a -30°C to 85°C temperature range and boasts a 1000 cycle electrical life. The nylon, polyamide actuator has a 2.1mm length and the housing is black with a UL94 V-0 flammability rating.

MountingSurface Mount

Quick Jump:

Technical Specifications

TE Connectivity 4-1571999-5 technical specifications.

General

Actuator Length	2.1mm
Actuator Material	Nylon, Polyamide
Actuator Type	PIANO
Contact Current Rating	1A
Contact Material	Copper Alloy
Contact Plating	Gold
Contact Post Length	4mm
Electrical Life	1000Cycles
ELV	Compliant
Flammability Rating	UL94 V-0
Height	0.236inch
Housing Color	Black
Length	12.14mm
Max Current Rating	100mA
Max Operating Temperature	85°C
Min Operating Temperature	-30°C
Max Voltage Rating (DC)	24V
Mount	Surface Mount
Number of Positions	4
Orientation	Straight
Package Quantity	35
Packaging	Rail/Tube
Pitch	0.1inch
Radiation Hardening	No
RoHS Compliant	Yes
Sealable	No (Without)
Series	ADPA
Terminal Pitch	2.54mm
Termination	Gull Wing
Throw Configuration	SPST
Type	Switch
DC Rated Voltage	5V
Washable	Yes
