5VDC non-latching signal relay featuring a DPDT contact configuration with a 3A contact current rating. This through-hole mount relay offers silver/gold contact material with gold plating, a 220V DC contact voltage rating, and 400mW coil power. Operating across a -40°C to 85°C temperature range, it boasts a 6ms operate time and 4ms release time, with IP67 sealing and RoHS compliance.
Sign in to ask questions about the TE Connectivity V23105-A5401-A201 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity V23105-A5401-A201 technical specifications.
| Actuating System | AC/DC |
| Coil Current | 80mA |
| Coil Power | 400mW |
| Coil Resistance | 62R |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 5V |
| Contact Current Rating | 3A |
| Contact Material | Silver, Gold |
| Contact Plating | Gold |
| Contact Voltage Rating (DC) | 220V |
| ELV | Compliant |
| Height | 0.433inch |
| Insertion Loss | -0.27dB |
| Length | 20.2mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Operate Time | 6ms |
| Packaging | Rail/Tube |
| Power Consumption | 400mW |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Relay Type | Relay |
| Release Time | 4ms |
| RoHS Compliant | Yes |
| Series | V23105, AXICOM |
| Switching Current | 3A |
| Termination | PCB |
| Throw Configuration | DPDT |
| Weight | 6g |
| Width | 10mm |
| RoHS | Compliant |
