DPDT signal relay with a 24VDC coil voltage and 3A contact current rating. Features silver/gold contact material with gold plating, 250VAC/220VDC max voltage rating, and a 550mW coil power. Through-hole mounting with PCB termination, this relay offers a 6ms operate time and 4ms release time, with a mechanical life of 300,000 hours. Operating temperature range is -40°C to 85°C, with IP67 environmental protection.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity V23105A5505A201 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuating System | AC/DC |
| Package/Case | DIP |
| Coil Current | 22.86mA |
| Coil Power | 550mW |
| Coil Resistance | 1.05kR |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24V |
| Contact Current Rating | 3A |
| Contact Material | Silver, Gold |
| Contact Plating | Gold |
| Contact Voltage Rating (DC) | 220V |
| Depth | 10mm |
| Height | 0.433inch |
| Insertion Loss | -0.27dB |
| Length | 20.2mm |
| Life (Hours) | 300000Hour |
| Max Current Rating | 3A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 220V |
| Mount | Through Hole, PCB |
| Number of Contacts | 2 |
| Operate Time | 6ms |
| Packaging | Rail/Tube |
| Power Consumption | 550mW |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Relay Type | Relay |
| Release Time | 4ms |
| RoHS Compliant | Yes |
| Series | V23105, AXICOM |
| Switching Current | 3A |
| Termination | PCB |
| Throw Configuration | DPDT |
| Weight | 6g |
| Width | 10mm |
| RoHS | Compliant |
