16-bit bidirectional bus transceiver with 3-state outputs, operating at 3.3V. Features 2.8ns propagation delay, 64mA low-level output current, and -32mA high-level output current. This surface-mount device is housed in a VFBGA package with copper, tin, and silver contact plating. Suitable for operation between -40°C and 85°C, it offers a non-inverting logic function and is RoHS compliant.
PackageVFBGA
MountingSurface Mount
PolarityNon-Inverting
Quick Jump:
Technical Specifications
Texas Instruments 74LVTH162245ZQLR technical specifications.
General
| Package/Case | VFBGA |
| Contact Plating | Copper, Tin, Silver |
| Direction | Bidirectional |
| High Level Output Current | -32mA |
| Lead Free | Lead Free |
| Logic Function | Transceiver, Inverting |
| Low Level Output Current | 64mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Number of Bits | 16 |
| Number of Bits per Element | 8 |
| Number of Circuits | 2 |
| Number of Elements | 2 |
| Operating Supply Voltage | 3.3V |
| Output Type | 3-STATE |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| Polarity | Non-Inverting |
| Propagation Delay | 2.8ns |
| Quiescent Current | 5mA |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | 74LVTH |
| Weight | 0.002116oz |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments 74LVTH162245ZQLR Datasheet
Download the complete datasheet for Texas Instruments 74LVTH162245ZQLR to view detailed technical specifications.
