The ADS8413IBRGZR is a 16-bit 1-channel analog-to-digital converter with a conversion rate of 2000KS/s. It operates over a temperature range of -40°C to 85°C and is available in a VQFN-48 package. The device is designed for surface mount applications and is compliant with RoHS regulations. It consumes a maximum power of 320mW and has a signal-to-noise ratio of 92dB. The ADS8413IBRGZR is suitable for use in a variety of applications, including data acquisition and industrial control systems.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments ADS8413IBRGZR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments ADS8413IBRGZR technical specifications.
| Package/Case | VQFN |
| Conversion Rate | 2000KS/s |
| Interface | LVDS, Serial |
| Lead Free | Contains Lead |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 320mW |
| Mount | Surface Mount |
| Number of Bits | 16 |
| Number of Channels | 1 |
| Number of Converters | 1 |
| Operating Supply Voltage | 5V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Power Consumption | 155mW |
| Resolution | 16b |
| RoHS Compliant | Yes |
| Sampling Rate | 2000000S/s |
| Signal to Noise Ratio (SNR) | 92dB |
| Supply Type | Analog, Digital |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments ADS8413IBRGZR to view detailed technical specifications.
