12-bit analog monitoring and control circuitry featuring 16 analog inputs and 12 DAC channels. This integrated circuit offers 16 A/D converters with a sampling rate of 500 kS/s and a 2.5V reference voltage. Communication interfaces include I2C and SPI, with 8 GPIO pins available. Operating within a 3V to 5V supply range, it supports a maximum power dissipation of 95mW and operates from -40°C to 105°C. The component is surface mountable in a VQFN package with gold contact plating and is RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments AMC7812SRGCT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments AMC7812SRGCT technical specifications.
| Package/Case | VQFN |
| Contact Plating | Gold |
| Interface | I2C, SPI |
| Lead Free | Lead Free |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 95mW |
| Max Supply Voltage | 5V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of A/D Converters | 16 |
| Number of Bits | 12 |
| Number of Channels | 16 |
| Number of Converters | 12 |
| Number of DAC Channels | 12 |
| Number of GPIO | 8 |
| Package Quantity | 250 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reference Voltage | 2.5V |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Sampling Rate | 500000S/s |
| Supply Type | Analog, Digital |
| Weight | 0.008021oz |
| RoHS | Compliant |
