Texas Instruments
BQ24004PWP
2-cell, 1.2-A, linear Li-ion battery charger with integrated FET and one LED 20-HTSSOP 0 to 70
PackageHTSSOP
Quick Jump:
Technical Specifications
Texas Instruments BQ24004PWP technical specifications.
General
Package/Case
HTSSOP
Contact Plating
Gold
Lead Free
Lead Free
Max Charge Current
1.2A
Min Input Voltage
4.5V
Max Operating Temperature
70°C
Min Operating Temperature
-40°C
Max Supply Voltage
10V
Min Supply Voltage
4.5V
Number of Cells
2
Number of Channels
1
Output Current
1.2A
Output Voltage
8.4V
Package Quantity
70
Packaging
Rail/Tube
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Weight
0.002885oz
Compliance
RoHS
Compliant
Datasheet
Texas Instruments BQ24004PWP Datasheet
Download the complete datasheet for Texas Instruments BQ24004PWP to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
