2-output, 1-input clock fanout buffer designed for high-speed applications. Features a 1:2 clock distribution with a maximum frequency of 250MHz. Operates from a 2.3V to 3.6V supply voltage and offers a propagation delay of 2ns. Packaged in an 8-pin TSSOP with gold contact plating, suitable for surface mounting. This RoHS compliant component is supplied on tape and reel.
Frequency250MHz
PackageTSSOP
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments CDCLVC1102PWR technical specifications.
General
Package/Case
TSSOP
Contact Plating
Gold
Frequency
250MHz
Input
LVCMOS
Lead Free
Lead Free
Max Frequency
250MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
3.6V
Min Supply Voltage
2.3V
Mount
Surface Mount
Number of Circuits
1
Number of Outputs
2
Package Quantity
2000
Packaging
Tape and Reel
Propagation Delay
2ns
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Turn-On Delay Time
10ns
Compliance
RoHS
Compliant
Datasheet
Texas Instruments CDCLVC1102PWR Datasheet
Download the complete datasheet for Texas Instruments CDCLVC1102PWR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
