The CY74FCT163CTQCT is a 4-bit synchronous counter from Texas Instruments, fabricated using CMOS technology. It operates within a temperature range of -40°C to 85°C and is supplied with a voltage of 5V. The counter features a propagation delay of 7.8ns and is available in a lead-free SSOP16 package, packaged in tape and reel quantities of 2500. The device is RoHS compliant and suitable for surface mount applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments CY74FCT163CTQCT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SSOP |
| Clock Edge Trigger Type | Positive Edge |
| Contact Plating | Gold |
| Direction | Up, Unidirectional |
| Lead Free | Lead Free |
| Logic Function | Counter |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.25V |
| Min Supply Voltage | 4.75V |
| Mount | Surface Mount |
| Number of Bits | 4 |
| Number of Bits per Element | 4 |
| Number of Elements | 1 |
| Operating Supply Voltage | 5V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Propagation Delay | 7.8ns |
| Reset | Synchronous |
| RoHS Compliant | Yes |
| Series | 74FCT |
| Technology | CMOS |
| Weight | 0.002628oz |
| RoHS | Compliant |
