Octal Bus Transceiver, 8-bit, bidirectional, 3-state outputs, CMOS technology, non-inverting logic function. Features Gold contact plating, SOIC package, and surface mount termination. Operates from 4.75V to 5.25V with a typical 5V supply voltage. Offers 64mA low-level output current and -32mA high-level output current. Supports an operating temperature range of -40°C to 85°C with a propagation delay of 4.1ns.
PackageSOIC
MountingSurface Mount
PolarityNon-Inverting
Quick Jump:
Technical Specifications
Texas Instruments CY74FCT245CTSOC technical specifications.
General
Package/Case
SOIC
Contact Plating
Gold
Direction
Bidirectional
High Level Output Current
-32mA
Lead Free
Lead Free
Logic Function
Transceiver, Inverting
Low Level Output Current
64mA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.25V
Min Supply Voltage
4.75V
Mount
Surface Mount
Number of Bits
8
Number of Bits per Element
8
Number of Channels
8
Number of Circuits
8
Number of Elements
1
Operating Supply Voltage
5V
Output Type
3-STATE
Package Quantity
25
Packaging
Rail/Tube
Polarity
Non-Inverting
Propagation Delay
4.1ns
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
74FCT
Technology
CMOS
Termination
SMD/SMT
Turn-On Delay Time
5.8ns
Weight
0.017662oz
Compliance
RoHS
Compliant
