8-bit digital-to-analog converter featuring a single channel and parallel interface. Offers 8-bit resolution with an integral nonlinearity of 0.19 LSB and a settling time of 150 ns. Operates with dual supply voltages from 4.5V to 18V, consuming 33mW of power. Packaged in a 16-PDIP for through-hole mounting, with a maximum power dissipation of 1W.
PackagePDIP
Current4.3mA
MountingThrough Hole
Power33mW
Quick Jump:
Technical Specifications
Texas Instruments DAC0808LCN technical specifications.
General
| Package/Case | PDIP |
| Differential Output | No |
| Integral Nonlinearity (INL) | 0.19LSB |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Min Dual Supply Voltage | 4.5V |
| Max Operating Temperature | 75°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 305mW |
| Max Supply Voltage | 18V |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Channels | 1 |
| Number of Converters | 1 |
| Number of D/A Converters | 1 |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Power Consumption | 33mW |
| Power Dissipation | 1W |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Resolution | 8b |
| RoHS Compliant | No |
| Settling Time | 150ns |
| Supply Current | 4.3mA |
Compliance
| RoHS | Not CompliantNo |
Datasheet
Texas Instruments DAC0808LCN Datasheet
Download the complete datasheet for Texas Instruments DAC0808LCN to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
