TEXAS INSTRUMENTS

DS15MB200TSQ/NOPB

Datasheet

1.5Gbps LVDS Mux/Buffer, 2:1/1:2, 3-Ch, 3V-3.6V, SM

Texas Instruments

DS15MB200TSQ/NOPB

Name: DS15MB200TSQ/NOPB Texas Instruments
Brand: Texas Instruments
SKU: DS15MB200TSQ/NOPB

1.5Gbps LVDS Mux/Buffer, 2:1/1:2, 3-Ch, 3V-3.6V, SM

Dual 1.5 Gbps LVDS Mux/Buffer with Pre-Emphasis, this interface IC offers 2:1/1:2 multiplexing and buffering capabilities. Featuring a 3.3V operating supply voltage, it supports a data rate of 1500Mbps with a propagation delay of 2.5ns. Designed for surface mount, this component operates across a temperature range of -40°C to 85°C.

MountingSurface Mount

Power743W

Quick Jump:

Technical Specifications

Texas Instruments DS15MB200TSQ/NOPB technical specifications.

General

Data Rate	1500Mbps
Height	0.8mm
Input	CML
Lead Free	Lead Free
Length	7mm
Logic Function	Buffer, Mux
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Max Power Dissipation	5.2W
Max Supply Current	275mA
Max Supply Voltage	3.6V
Min Supply Voltage	3V
Mount	Surface Mount
Number of Channels	2
Number of Circuits	2
Number of Drivers	3
Number of Elements	3
Number of Receivers	3
Operating Supply Current	225mA
Operating Supply Voltage	3.3V
Packaging	Tape and Reel
Power Consumption	743W
Power Dissipation	5.2W
Propagation Delay	2.5ns
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Turn-On Delay Time	2.5ns
Width	7mm
