Half-duplex line transceiver for RS-422 and RS-485 interfaces, operating at up to 10Mbps. Features a single driver and single receiver within a DIP package, requiring through-hole mounting. This component has a maximum supply voltage of 5.25V and a typical supply current of 60mA, with an operating temperature range of 0°C to 70°C. Dimensions are 9.27mm length, 6.35mm width, and 3.3mm height.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments DS3695N datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments DS3695N technical specifications.
| Package/Case | DIP |
| Data Rate | 10Mbps |
| ESD Protection | No |
| Height | 3.3mm |
| Interface | RS-422, RS-485 |
| Lead Free | Contains Lead |
| Length | 9.27mm |
| Logic Function | Transceiver |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Current | 60mA |
| Max Supply Voltage | 5.25V |
| Min Supply Voltage | 4.75V |
| Mount | Through Hole |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Number of Transceivers | 1 |
| Number of Transmitters | 1 |
| Operating Supply Voltage | 5V |
| Package Quantity | 40 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Simplex/Duplex | Half Duplex |
| Supply Current | 60mA |
| Width | 6.35mm |
| RoHS | Not CompliantNo |
