FPD-Link III Serializer, a 24-bit color interface IC, supports data rates up to 2.975Gbps with a maximum frequency of 85MHz. This surface mount component features 24 inputs and 1 output, operating at a 3.3V supply voltage. It includes a bidirectional control channel and an I2C interface, with a wide operating temperature range of -40°C to 105°C. Designed for automotive applications and AEC-Q100 qualified, this lead-free and RoHS compliant device is supplied in tape and reel packaging.
Frequency85MHz
Current148mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments DS90UB925QSQX/NOPB technical specifications.
General
| Data Rate | 2.975Gbps |
| Interface | I2C |
| Lead Free | Lead Free |
| Max Frequency | 85MHz |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Drivers | 1 |
| Number of Elements | 1 |
| Number of Inputs | 24 |
| Number of Outputs | 1 |
| Number of Receivers | 24 |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q100 |
| Supply Current | 148mA |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments DS90UB925QSQX/NOPB Datasheet
Download the complete datasheet for Texas Instruments DS90UB925QSQX/NOPB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
