Single-channel transimpedance amplifier IC featuring a 2MHz gain bandwidth product and 3V/µs slew rate. Operates with dual supply voltages up to ±18V, with a typical operating supply voltage of 15V and a supply current of 4.1mA. Offers a low input bias current of 0.75pA and an input offset voltage of 500µV. Packaged in a 14-pin SOIC (D) with dimensions of 8.65mm length, 3.91mm width, and 1.58mm height. RoHS compliant and lead-free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments IVC102U datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments IVC102U technical specifications.
| Package/Case | D |
| Common Mode Rejection Ratio | 90dB |
| Dual Supply Voltage | 15V |
| Gain Bandwidth Product | 2MHz |
| Height | 1.58mm |
| Input Bias Current | 0.75pA |
| Input Offset Voltage (Vos) | 500uV |
| Lead Free | Lead Free |
| Length | 8.65mm |
| Max Dual Supply Voltage | 18V |
| Max I/O Voltage | 5mV |
| Max Input Current | 100uA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 36V |
| Min Supply Voltage | 4.75V |
| Nominal Gain Bandwidth Product | 2MHz |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Operating Supply Current | 4.1mA |
| Operating Supply Voltage | 15V |
| Output Current per Channel | 20mA |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | IVC102 |
| Slew Rate | 3V/µs |
| Supply Current | 4.1mA |
| Unity Gain Bandwidth Product | 2MHz |
| Weight | 0.004564oz |
| Width | 3.91mm |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments IVC102U to view detailed technical specifications.
