The Texas Instruments JM38510/11201BDA is a 4-channel BIPOLAR specialty logic IC with a common mode rejection ratio of 70dB and an input offset voltage of 5mV. It operates within a temperature range of -55°C to 125°C and is available in a surface mount package. The device is not RoHS compliant and contains lead, making it a non-lead-free component. It has a maximum power dissipation of 350mW and a maximum supply voltage of 36V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments JM38510/11201BDA datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments JM38510/11201BDA technical specifications.
| Common Mode Rejection Ratio | 70dB |
| Input Offset Voltage (Vos) | 5mV |
| Lead Free | Contains Lead |
| Max Dual Supply Voltage | 18V |
| Min Dual Supply Voltage | 2.5V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Supply Current | 2mA |
| Max Supply Voltage | 36V |
| Min Supply Voltage | 5V |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Packaging | Rail/Tube |
| Power Dissipation | 350mW |
| Radiation Hardening | No |
| RoHS Compliant | No |
| Supply Current | 2mA |
| Technology | BIPOLAR |
| Voltage Gain | 93.98dB |
| RoHS | Not CompliantNo |
