The LF198H is a dual supply operational amplifier available in a TO-99-8 package. It has a common mode rejection ratio of 94dB and can operate with a dual supply voltage between 5V and 18V. The device is designed for use in through hole mounting and has a maximum operating temperature of 125°C and a minimum operating temperature of -55°C. The LF198H is not RoHS compliant and contains lead.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LF198H datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | TO-99-8 |
| Common Mode Rejection Ratio | 94dB |
| Dual Supply Voltage | 15V |
| Height | 4.45mm |
| Input Bias Current | 5nA |
| Input Offset Voltage (Vos) | 1mV |
| Lead Free | Contains Lead |
| Length | 9.14mm |
| Max Dual Supply Voltage | 18V |
| Min Dual Supply Voltage | 5V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Operating Supply Current | 4.5mA |
| Operating Supply Voltage | 15V |
| Package Quantity | 500 |
| Packaging | Bulk |
| RoHS Compliant | No |
| Width | 9.14mm |
| RoHS | Not Compliant |
