The LM109H is a linear voltage regulator with a fixed output voltage of 5.05V and an output current of 200mA. It operates over a temperature range of -55°C to 150°C and is packaged in a TO-39-3 case with a through-hole mount. The device is RoHS compliant and has a quiescent current of 10mA. It can handle a maximum input voltage of 35V and a maximum output current of 1A.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM109H datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | TO-39-3 |
| Dropout Voltage | 3V |
| Height | 4.45mm |
| Lead Free | Contains Lead |
| Length | 9.14mm |
| Max Input Voltage | 35V |
| Min Input Voltage | 7.1V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Output Current | 1A |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Number of Regulators | 1 |
| Output Current | 200mA |
| Output Type | Fixed |
| Output Voltage | 5.05V |
| Package Quantity | 500 |
| Packaging | Bulk |
| Polarity | Positive |
| Quiescent Current | 10mA |
| RoHS Compliant | Yes |
| Width | 9.14mm |
| RoHS | Compliant |
