Single, general-purpose operational amplifier featuring a 1MHz gain bandwidth product and 0.4V/µs slew rate. This surface-mount device in a SOT-23-5 package operates from a 1.5V to 30V supply range, with a typical operating supply voltage of 16V and a low operating supply current of 660µA. It offers a 100dB voltage gain, 65dB common mode rejection ratio, and 65dB power supply rejection ratio, with an input bias current of 250nA and an input offset voltage of 7mV. Suitable for operation between -40°C and 85°C, this RoHS compliant component is supplied on tape and reel.
PackageSOT-23-5
Voltage30V
Current1.15mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LM321MFX/NOPB technical specifications.
General
| Amplifier Type | GENERAL PURPOSE |
| Bandwidth | 1MHz |
| Package/Case | SOT-23-5 |
| Common Mode Rejection Ratio | 65dB |
| Gain Bandwidth Product | 1MHz |
| Input Bias Current | 250nA |
| Input Offset Voltage (Vos) | 7mV |
| Lead Free | Lead Free |
| Max Dual Supply Voltage | 15V |
| Min Dual Supply Voltage | 1.5V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Amplifiers | 1 |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Operating Supply Current | 660uA |
| Operating Supply Voltage | 16V |
| Output Current | 40mA |
| Output Current per Channel | 40mA |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Power Supply Rejection Ratio (PSRR) | 65dB |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Slew Rate | 0.4V/µs |
| Supply Current | 1.15mA |
| Technology | BIPOLAR |
| Unity Gain Bandwidth Product | 1MHz |
| Voltage | 30V |
| Voltage Gain | 100dB |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments LM321MFX/NOPB Datasheet
Download the complete datasheet for Texas Instruments LM321MFX/NOPB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
