LM358N/NOPB

Datasheet

2-Ch Op Amp, 1MHz, 32V, PDIP, Through Hole

Texas Instruments

LM358N/NOPB

Name: LM358N/NOPB Texas Instruments
Brand: Texas Instruments
SKU: LM358N/NOPB
Price: 1.276 USD
Availability: InStock

2-Ch Op Amp, 1MHz, 32V, PDIP, Through Hole

Dual-channel, general-purpose operational amplifier with a 1MHz bandwidth and 32V maximum supply voltage. Features include a 0.1V/µs slew rate, 100dB voltage gain, and 65dB common mode rejection ratio. This bipolar technology amplifier is housed in a through-hole PDIP package, suitable for operation between 0°C and 70°C. Maximum power dissipation is 830mW, with a typical supply current of 1mA.

PackagePDIP

Current500uA

MountingThrough Hole

Power830mW

Quick Jump:

Pricing & Availability

Distributor	Stock	Min Qty	1+	10+	12+	25+	Package Type	Action
Quest	12 In Stock	12	-	-	1.276	-	-	View
TME	-	1	0.941	0.682	-	0.621	pcs	View

Chat with Datasheet

Technical Specifications

Texas Instruments LM358N/NOPB technical specifications.

General

Amplifier Type	GENERAL PURPOSE
Bandwidth	1MHz
Package/Case	PDIP
Common Mode Rejection Ratio	65dB
Gain Bandwidth Product	1MHz
Height	3.3mm
Input Bias Current	250nA
Input Offset Voltage (Vos)	7mV
Lead Free	Lead Free
Length	9.27mm
Max Dual Supply Voltage	16V
Min Dual Supply Voltage	1.5V
Max Operating Temperature	70°C
Min Operating Temperature	0°C
Max Power Dissipation	830mW
Max Supply Current	1.2mA
Max Supply Voltage	32V
Min Supply Voltage	3V
Mount	Through Hole
Number of Amplifiers	2
Number of Channels	2
Number of Circuits	2
Number of Elements	2
Operating Supply Current	1mA
Operating Supply Voltage	16V
Output Current	30mA
Output Current per Channel	40mA
Package Quantity	40
Packaging	Rail/Tube
Power Dissipation	830mW
Power Supply Rejection Ratio (PSRR)	65dB
Radiation Hardening	No
Reach SVHC Compliant	No
Slew Rate	0.1V/µs
Supply Current	500uA
Technology	BIPOLAR
Unity Gain Bandwidth Product	1MHz
Voltage Gain	100dB
Width	6.35mm
