The LM3881MME/NOPB is a 3-channel voltage monitor with a watchdog timer, suitable for operating within a temperature range of -40°C to 125°C. It is packaged in an MSOP-8 package and is RoHS compliant. The device monitors three voltages and has a quiescent current of 80uA. It can operate with a supply voltage between 2.7V and 5.5V.
PackageMSOP
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LM3881MME/NOPB technical specifications.
General
| Package/Case | MSOP |
| Height | 0.86mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Number of Voltages Monitored | 3 |
| Operating Supply Current | 80uA |
| Overvoltage Threshold | 1.22V |
| Package Quantity | 250 |
| Packaging | Tape and Reel |
| Quiescent Current | 80uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Threshold Voltage | 1.22V |
| Undervoltage Threshold | 500mV |
| Watchdog Timer | No |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments LM3881MME/NOPB Datasheet
Download the complete datasheet for Texas Instruments LM3881MME/NOPB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
