High-fidelity 68W, single-channel audio amplifier IC in a TO-220 package. Features a 8MHz gain bandwidth product and 120dB PSRR for exceptional audio performance. Operates with dual supply voltages from ±10V to ±28V, with a maximum supply voltage of ±42V. Delivers up to 68W output power into an 8Ω load, with a maximum output current of 11.5A. Designed for through-hole mounting and a maximum power dissipation of 125W.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM3886T datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments LM3886T technical specifications.
| Package/Case | TO-220 |
| Dual Supply Voltage | 28V |
| Gain Bandwidth Product | 8MHz |
| Input Bias Current | 1uA |
| Input Offset Voltage (Vos) | 10mV |
| Load Impedance | 8R |
| Max Dual Supply Voltage | 42V |
| Min Dual Supply Voltage | 10V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Max Output Power | 68W |
| Max Power Dissipation | 125W |
| Max Supply Voltage | 84V |
| Min Supply Voltage | 20V |
| Mount | Through Hole |
| Number of Channels | 1 |
| Output Current | 11.5A |
| Output Power | 68W |
| Package Quantity | 20 |
| Packaging | Rail/Tube |
| Power Dissipation | 125W |
| Power Supply Rejection Ratio (PSRR) | 120dB |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Series | Overture™ |
| Supply Type | Single, Dual |
| Unity Gain Bandwidth Product | 8MHz |
| RoHS | Not Compliant |
Download the complete datasheet for Texas Instruments LM3886T to view detailed technical specifications.
