The LM46001 is an adjustable DC/DC controller with a maximum output current of 1A and a maximum output voltage of 28V. It operates over a wide input voltage range of 3.5V to 60V and is suitable for surface mount applications. The device is RoHS compliant and features a low quiescent current of 24uA. It is available in a lead-free HTSSOP package and is suitable for use in a variety of applications, including DC/DC converters and power supplies.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM46001PWPR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments LM46001PWPR technical specifications.
| Package/Case | HTSSOP |
| Lead Free | Lead Free |
| Max Input Voltage | 60V |
| Min Input Voltage | 3.5V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 28V |
| Min Output Voltage | 1V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Configuration | Positive |
| Output Current | 1A |
| Output Type | Adjustable |
| Packaging | Cut Tape |
| Quiescent Current | 24uA |
| RoHS Compliant | Yes |
| Series | SIMPLE SWITCHER® |
| Synchronous Rectifier | Yes |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments LM46001PWPR to view detailed technical specifications.
