The LM5025MTCX/NOPB is a PowerWise DC/DC controller from Texas Instruments, packaged in a TSSOP-16 package, suitable for surface mount. It operates over a temperature range of -40°C to 125°C and is compliant with RoHS regulations. The device has a maximum output power of 300W and a maximum frequency of 1MHz, with a duty cycle of up to 80%. The LM5025MTCX/NOPB is a single-channel device with one output.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM5025MTCX/NOPB datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments LM5025MTCX/NOPB technical specifications.
| Package/Case | TSSOP |
| Duty Cycle | 80% |
| Fall Time | 15ns |
| Lead Free | Lead Free |
| Max Duty Cycle | 80% |
| Max Frequency | 1MHz |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Outputs | 1 |
| Output Power | 300W |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | PowerWise® |
| Thickness | 1mm |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments LM5025MTCX/NOPB to view detailed technical specifications.
