Dual-channel, half-bridge gate driver for GaNFETs, featuring independent channels with a maximum output current of 5A. This surface-mount component operates with a supply voltage range of 4.5V to 5.5V, offering a 1.5ns fall time and 28ns turn-on delay. Maximum operating temperature reaches 125°C, with a minimum of -40°C. Packaging is provided on tape and reel, with 250 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM5113TME/NOPB datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments LM5113TME/NOPB technical specifications.
| Channel Type | Independent |
| Fall Time | 1.5ns |
| Lead Free | Lead Free |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 5A |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Drivers | 2 |
| Number of Outputs | 2 |
| Operating Supply Current | 2mA |
| Output Current | 5A |
| Package Quantity | 250 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Turn-Off Delay Time | 26.5ns |
| Turn-On Delay Time | 28ns |
| RoHS | Compliant |
